MechanoCulture TX
High throughput uniaxial compression stimulation machine
The MCTX test machine can uniaxially compress 3-dimensional specimens in 6 independent wells. A user-specified loading protocol is enacted by the system and the resulting force-displacement data is recorded to determine the stiffness profile of each specimen as a function of time. The transparent culture wells allow for visual confirmation of correct specimen loading and real-time imaging during the test if desired. The specimen chamber plate can be sterilized and the system is suitable for long-term cell culture in a laboratory incubator.
Key Features
- Compression stimulation of 6 culture wells in a reusable holder.
- Displacement-controlled loading up to 2 mm at 2Hz
- Simultaneous position measurement on all wells with 1µm resolution
- User-friendly interface software for specifying simple, cyclic, and intermittent stimulation protocols for download to the device controller
Videos
MCTX Introduction
TECHNICAL INFO
| Dimensions | 16 X 19 X 16 cm |
| Weight | 4.1 kg |
| Specimen Dimensions |
Up to 20 mm diameter/width and 25 mm thick |
| Number of wells | 6 |
| Available load cells | 10, 20, 50, 100 N |
| Force Accuracy | Approx. 0.2% of transducer capacity |
| Maximum Displacement | 2 mm |
| Maximum Velocity | 4 mm/s |
| Maximum Cycle Frequency | 2 Hz |
